Vacuum Isolate Globe Valve

The sizes of valve connecting flange and butt-welding terminas can be designed according to customer's requirement.

Email : panlijuan@bgjx.cn

WhatsApp : +8618136395626

PDF Download

Product Details

Main size of outside & weight：

PN(MPa)	DN(mm)	L	D	Dn	D1	L1	H	H1	D0	Weight(Kg)
1.6	10	130	36	9	15	9	245	255	120	6.5
1.6	15	130	36	12	19	10	245	260	120	7
1.6	20	150	44	19	26	11	265	285	140	7.8
1.6	25	160	44	26	33	13	270	293	160	8.5
1.6	32	180	60	30	39	14	270	300	180	12
2.5	10	130	36	9	15	9	245	255	120	6.5
2.5	15	130	36	12	19	10	245	260	120	7
2.5	20	150	44	19	26	11	265	285	140	7.8
2.5	25	160	44	26	33	13	270	293	160	8.5
2.5	32	180	60	30	39	14	270	300	180	12
4.0	10	130	36	9	15	9	245	255	120	6.5
4.0	15	130	36	12	19	10	245	260	120	7
4.0	20	150	44	19	26	11	265	285	140	7.8
4.0	25	160	44	26	33	13	270	295	160	8.5
4.0	32	180	60	30	39	14	270	300	180	12
6.4	10	130	36	9	15	9	245	255	120	6.5
6.4	15	130	36	12	19	10	245	260	140	7
6.4	20	150	44	19	26	11	270	290	160	7.8
6.4	25	160	44	26	33	13	290	315	180	8.5
6.4	32	180	60	30	39	14	330	360	200	13
10.0	10	130	36	9	15	9	245	255	120	7
10.0	15	130	36	12	19	10	245	260	140	7.6
10.0	20	150	44	19	26	11	270	290	160	8.7
10.0	25	160	50	26	33	13	290	315	180	10.5
10.0	32	180	60	30	39	14	330	360	200	16
